Automatic Transfer Switch
Automatic Transfer Switches (ATS) made by Powercity are designed in conformance with European Standards and are certified by independent testing laboratory. Tested in conformity with European Standards EN 55011:2007 and EN 61000-4 and certified by SAPO Certification and Testing Laboratory Limited of United Kingdom with certificate number SP1001GZ1111414 and SP1001GZ1111415. An ATS is the component in an emergency and standby power system that transfers power from the “normal” power source to the alternate power source when the “normal” source of power fails. An automatic transfer switch transfers power between two power sources without requiring the intervention of an operator. Article 7.0.1.6 of the Philippine Electrical Code (PEC) requires the use of ATS to protect your generator, your home or business and grid supply linemen.
PTS-125
| MODEL | PTS-125 | ||
| Rated Ampere | 125A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Solenoid type | ||
| No. of Poles | 2P | 3P or 4P | |
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 48(L) x 23(W) x 60(H) | ||
| Weight | 25Kg | ||
(Specifications are subject to change without prior notice.)
PTS-225
| MODEL | PTS-225 | ||
| Rated Ampere | 225A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Motorize type | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 38(L) x 27(W) x 60(H) | ||
| Weight | 30Kg | ||
(Specifications are subject to change without prior notice.)
PTS-250
| MODEL | PTS-250 | ||
| Rated Ampere | 250A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Motorized type | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 77(L) x 49(W) x 28(H) | ||
| Weight | 50Kg | ||
(Specifications are subject to change without prior notice.)
PTS-400
| MODEL | PTS-400 | ||
| Rated Ampere | 400A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Motorize type | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | Free Standing NEMA 1 | ||
| Dimensions (cm) | 60(L) x 54(W) x 160(H) | ||
| Weight | 130Kg | ||
(Specifications are subject to change without prior notice.)
PTS-1000
| MODEL | PTS-1000 | ||
| Rated Ampere | 1000A | ||
| Phase | 3Ø | ||
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Solenoid type | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | Free standing NEMA 1 | ||
| Dimensions (cm) | 90(L) x 90(W) x 192(H) | ||
| Weight | 290 Kg | ||
(Specifications are subject to change without prior notice.)
PTS-1800
| MODEL | PTS-1800 | ||
| Rated Ampere | 1800A | ||
| Phase | 3Ø | ||
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Solenoid type | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | Free standing NEMA 1 | ||
| Dimensions (cm) | 90(L) x 90(W) x 192(H) | ||
| Weight | 290 Kg | ||
(Specifications are subject to change without prior notice.)
PTS-2500
| MODEL | PTS-2500 | |||
| Rated Ampere | 2500A | |||
| Phase | 3Ø | |||
| Rated Voltage | 200~240V | 380~440V | ||
| Rated Frequency | 50Hz / 60Hz | |||
| Transfer Switch | Solenoid type | |||
| No. of Poles | 3P or 4P | |||
| Enclosure | Free standing NEMA 1 | |||
| Dimensions (cm) | 1000(L) x 1000(W) x 2210(H) | |||
| Weight | 250Kg | |||
(Specifications are subject to change without prior notice.)
PTS-125A-S
| MODEL | PTS-125A-S | ||
| Rated Ampere | 125A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Solenoid type | ||
| Surge protector | Model | V100E/320-S | |
| Max. continuous operating voltage | 320VAC/420VDC | ||
| Nominal discharge current(8/20) In (L-PE) | 20kA | ||
| Max. discharge current(8/20) Imax (L-PE) | 100kA | ||
| No. of Poles | 1P | 3P or 4P | |
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 48(L) x 23(W) x 61(H) | ||
| Weight | 30Kg | ||
(Specifications are subject to change without prior notice.)
PTS-250AX-S
| MODEL | PTS-250AX-S | ||
| Rated Ampere | 250A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Solenoid type | ||
| Surge protector | Model | V100E/320-S | |
| Max. continuous operating voltage | 320VAC/420VDC | ||
| Nominal discharge current(8/20) In (L-PE) | 20kA | ||
| Max. discharge current(8/20) Imax (L-PE) | 100kA | ||
| No. of Poles | 1P | 3P or 4P | |
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 48(L) x 29(W) x 70(H) | ||
| Weight | 45Kg | ||
(Specifications are subject to change without prior notice.)
PTS-125A-CB
| MODEL | PTS-125A-CB | ||
| Rated Ampere | 125A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | ABB MCCB w/ interlocked transfer motor | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 60(L) x 25(W) x 70(H) | ||
| Weight | 50Kg | ||
(Specifications are subject to change without prior notice.)
PTS-250A-CB
| MODEL | PTS-250A-CB | ||
| Rated Ampere | 250A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | ABB MCCB w/ interlocked transfer motor | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 60(L) x 25(W) x 70(H) | ||
| Weight | 50Kg | ||
(Specifications are subject to change without prior notice.)
PTS-400A-CB
| MODEL | PTS-400A-CB | ||
| Rated Ampere | 400A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | ABB MCCB w/ interlocked transfer motor | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 75(L) x 35(W) x 80(H) | ||
| Weight | 70Kg | ||
(Specifications are subject to change without prior notice.)
PTS-400A-S
| MODEL | PTS-400A-S | ||
| Rated Ampere | 400A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | ABB MCCB w/ interlocked transfer motor | ||
| Surge protector | Model | V100E/320-S | |
| Max. continuous operating voltage | 320VAC/420VDC | ||
| Nominal discharge current(8/20) In (L-PE) | 20kA | ||
| Max. discharge current(8/20) Imax (L-PE) | 100kA | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 75(L) x 35(W) x 90(H) | ||
| Weight | 75Kg | ||
(Specifications are subject to change without prior notice.)
PTS-250A-S
| MODEL | PTS-250A-S | ||
| Rated Ampere | 250A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~440V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | ABB MCCB w/ interlocked transfer motor | ||
| Surge protector | Model | V100E/320-S | |
| Max. continuous operating voltage | 320VAC/420VDC | ||
| Nominal discharge current(8/20) In (L-PE) | 20kA | ||
| Max. discharge current(8/20) Imax (L-PE) | 100kA | ||
| No. of Poles | 3P or 4P | ||
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 60(L) x 25(W) x 80(H) | ||
| Weight | 55Kg | ||
(Specifications are subject to change without prior notice.)
PTS-400AX-S
| MODEL | PTS-400AX-S | ||
| Rated Ampere | 400A | ||
| Phase | 1Ø | 3Ø | |
| Rated Voltage | 200~240V | 380~480V | |
| Rated Frequency | 50Hz / 60Hz | ||
| Transfer Switch | Solenoid type | ||
| Surge protector | Model | V100E/320-S | |
| Max. continuous operating voltage | 320VAC/420VDC | ||
| Nominal discharge current(8/20) In (L-PE) | 20kA | ||
| Max. discharge current(8/20) Imax (L-PE) | 100kA | ||
| No. of Poles | 1P | 3P or 4P | |
| Enclosure | NEMA 3 | ||
| Dimensions (cm) | 66(L) x 34(W) x 84(H) | ||
| Weight | 65Kg | ||
(Specifications are subject to change without prior notice.)
DTS-32A-1P
| MODEL | DTS-32A-1P | ||
| Aircon Qty | UP to 3 units | ||
| Contact Capacity | Max.32A | ||
| Phase | Single Phase | ||
| Rated Voltage | 220 Vac + 15% | ||
| Rated Frequency | 50Hz / 60Hz | ||
| Temp. Precision | 0.25 °C | ||
| Temperature | 20~30°C, default 23°C | ||
| Under Temp. | 10~25°C, default 20°C | ||
| Over Temp. | 25~40°C, default 29°C | ||
| Under Voltage | 165~210 Vac, default 180Vac | ||
| Over Voltage | 230~277 Vac, default 250Vac | ||
| Under Current | 0~10 A, default 0A | ||
| Over Current | 5~50 A, default 20A | ||
| Change over time | 1~100h, default 12h | ||
| Dimensions (cm) | 26.5(D) x 40(W) x 33(H) | ||
| Weight | 16.5Kg |
(Specifications are subject to change without prior notice.)
