Load Bank

Load Bank
Load Banks made by Powercity are designed in conformance with European Standards and are certified by independent testing laboratory. Tested in conformity with European Standards EN 55011:2007 and EN 61000-4 and certified by SAPO Certification and Testing Laboratory Limited of United Kingdom with certificate number SP1001GZ1111416. Powercity Load Banks are designed to provide a stable and controllable load for determining the performance characteristics of AC generators. A load bank verifies the rated power of a generator set; it verifies if the engine is properly sized of has the sufficient mechanical power (kWm) to the drive the alternator at full load; it checks the efficiency of the cooling system; it detects problems of the generator; it decarbonizes engine and prevents wet stacking of diesel engine in generators operating on light load.
MODEL PDL-10
Rated Load 10 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 840 x 340 x 480
Weight (Kg) 30
(Specifications are subject to change without prior notice.)
MODEL PDL-15
Rated Load 15 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 640 x 400 x 910
Weight (Kg) 60
(Specifications are subject to change without prior notice.)
MODEL PDL-30
Rated Load 30 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 820 x 930 x 1300
Weight (Kg) 300
(Specifications are subject to change without prior notice.)
MODEL PDL-40
Rated Load 40 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 720 x 1050 x 1350
Weight (Kg) 260
(Specifications are subject to change without prior notice.)
MODEL PDL-50
Rated Load 50 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 720 x 1050 x 1350
Weight (Kg) 260
(Specifications are subject to change without prior notice.)
MODEL PDL-100
Rated Load 100 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 820 x 930 x 1300
Weight (Kg) 300
(Specifications are subject to change without prior notice.)
MODEL PDL – 600
Rated Load 0 ~ 600KW
Type of Load Resistive
Duty 200~240V
Cooling System 4 x 3kw Fan
Enclosure NEMA 1 ( Indoor )
Phase Available in Single phase or 3 phase Unit
Rated Voltage Dual Voltage Design 180~240V or 380~440V
Rated Frequency 50Hz / 60Hz
Load Step 10 Steps including a Variac
Dimensions (mm) 2100(L) x 1700(W) x 1970(H)
Dry Weight 250Kg
(Specifications are subject to change without prior notice.)
MODEL PDL-1200
Rated Load 1,200 Kilowatts
Rated Voltage 180-240 Volts AC
Rated Frequency 50/60 Hz
Phase
Dimensions LxWxH (mm) 2920 x 1700 x 2050
Weight (Kg) 3000
(Specifications are subject to change without prior notice.)
MODEL PDL-400
Rated Load 400 Kilowatts
Rated Voltage 180-240 Volts AC
Rate Frequency 50/60 Hz
Phase
Dimension LxWxH (mm) 1360 x 1270 x 1470
Weight (Kg) 1060

(Specifications are subject to change without prior notice.)
